DIGITAL MULTIMETER – CAT II 500V / CAT III 300 V – 10A
Digital multimeter, data hold, non-contact voltage detection, with REL function, suitable for measuring AC/DC current, AC/DC voltage, resistance, frequency, temperature, continuity, including test leads
Digital multimeter, LCD display, CAT III/600 V, suitable for measuring AC/DC voltage, resistance, temperature, transistors, diodes, and continuity, battery test, flashlight, NCV function, test leads
| Instruction manual languages | Dutch, English, French, German, Polish, Portuguese, Spanish |
| Primary colours | Grey, Red |
| Additional colours | Blue |
| Depth unit | 30 mm |
| Height unit | 119 mm |
| Width unit | 65 mm |
| Weight unit | 130 g |
| Material | ABS |
| Physical properties | |
|---|---|
| Cable length | 0.85 m |
| Display height | 26 mm |
| Display width | 43 mm |
| Display type | LCD |
| Backlight | |
| Maximum digits display | 4 |
| Electrical data | |
|---|---|
| Lamp type | Led |
| AC voltage | basic accuracy : ±(1.0%+10) |
| Audible continuity measurement | |
| Automatic polarity indication | |
| Diode test | |
| Continuity test | |
| Out of range indication | |
| Transistor test | |
| True rms | |
| AC voltage measurements | 2 V, 20 mV, 20 V, 200 mV, 200 V, 600 V |
| Battery test measurements | 1.5 V, 9 V |
| DC voltage measurements | 2 V, 20 mV, 20 V, 200 mV, 200 V, 600 V |
| Resistance measurements | 2 kOhm, 2 MOhm, 20 kOhm, 20 MOhm, 200 kOhm, 200 Ohm |
| Resistance specifications | basic accuracy : ±(1.0%+5) |
| Battery test | |
| Technical data | |
|---|---|
| Auto shut-off | |
| Safety rating | Cat III / 600 V |
| Voltage tester type | AC / DC |
| Automatic power-off function | |
| Data-hold function | |
| Relative value measurement | |
| Remote voltage test | |
| Environmental data | |
|---|---|
| IP rating | IPx0 |
| Usage location | Indoor only |
| Operational properties | |
|---|---|
| Measuring temperature range °C | -20-1000 °C |
| Measuring temperature range °F | -4-1832 °F |
| Number ranges | 7 |
| Range setting | Automatic |
| Power supply | |
|---|---|
| Batteries included | |
| Number of batteries | 2 |
| Low battery indicator | |
| Battery composition | Alkaline |
| Battery IEC size | AAA (LR03, R03, FR03, HR03, KR03, ZR03 ,24A, 24D, 24LF, UM4, Micro, MN2400, MX2400, MV2400) |
| Included | |
|---|---|
| with LED light | |
This digital multimeter is the perfect tool for occasional users (DIYers) who need a reliable instrument for essential measurements. Thanks to its compact and robust design, you can take it anywhere.
The multimeter is suitable for measuring voltage, temperature, and resistance with the provided test leads (100 cm). The device features a clear display with backlighting and an LED flashlight, making the measurements easy to read. With a safety rating of CAT III - 600 V and an NCV function, you are ensured safe use.
+ Integrated data hold function: With this feature, you can easily hold and read measurements even after disconnecting the test leads. This ensures accurate and reliable measurements.
+ Non-contact voltage detection: Thanks to the NCV function, you can safely detect the presence of voltage from a distance, without making direct contact with the cables.
+ Automatic shutdown: The multimeter automatically shuts off when not in use.
+ Temperature measurement and battery test function: With the included temperature probes, you can easily perform accurate temperature tests within a measuring range of -20°C to 1000°C. The multimeter also offers the ability to check the condition of various battery types.
+ Automatic polarity indication: Thanks to the automatic polarity indication, you don't have to worry about incorrectly connecting the test leads. This saves time and minimizes errors when conducting measurements.
